Triplanar笔记

这个笔记主要记录自CatlikeCoding-Triplanar 上面的文章很长而且有很多跟Triplanar无关的内容，其实triplanar和核心内容就是很简单的几行代码，所以看我这个笔记就可以了。

小学生都能看懂的视频版，求三连

什么是Triplanar?为什么要用Triplanar?

一般来说我们想要映射纹理到我们的模型上，可以用根据每个顶点的uv坐标来映射纹理。但这不是唯一的方法，而triplanar就是另一种映射贴图的方式。有时候，uv坐标映射的方式可能无法达到我们想要的效果（比如造成贴图拉伸）甚至根本没有uv坐标，这些情况大多在用代码生成模型时，动态改变模型时发生。Triplanar的原理就是用顶点位置作为uv坐标，用法线作为权重，来实现贴图的映射，因为映射已xyz三个平面分别映射，所以叫做tri-planar。

《A Short Hike》中的triplanar应用

Image title

先放源码

Shader "Custom/Triplanar" {
Properties {
        _TopTex("TopTexture", 2D) = "white" {}
        _SideTex("SideTexture", 2D) = "white" {}
        _BlendOffset("BlendOffset",Range(0,0.5)) = 0.25
        _BlendExponent ("Blend Exponent", Range(1, 8)) = 2
}
SubShader {
        Tags { "RenderType"="Opaque" }
Pass {
            CGPROGRAM
            #pragma vertex vert
            #pragma fragment frag
            #include "UnityStandardBRDF.cginc"
            #include "Assets/Plugins/GumouKit/cgincs/gfunc.cginc"

            struct appdata
            {
                float4 vertex : POSITION;
                float3 normal:NORMAL;
            };
            struct v2f
            {
                float4 vertex : SV_POSITION;
                float3 normal:TEXCOORD1;
                float4 worldpos : TEXCOORD2;
            };

            fixed _BlendOffset;
            half _BlendExponent;
            sampler2D _TopTex;
            sampler2D _SideTex;
            float4 _TopTex_ST,_SideTex_ST;

            struct TriUV{
                float2 xUV,yUV,zUV;
            };
            TriUV GetTriUV (float4 worldpos) {
                TriUV triUV;
                triUV.xUV = worldpos.zy;
                triUV.yUV = worldpos.xz;
                triUV.zUV = worldpos.xy;
                return triUV;
            }
            fixed3 GetTriWeights(fixed3 normal){
                fixed3 weights = abs(normal);   //因为normal可能有负数
                weights = saturate(weights-_BlendOffset);   //控制权重
                weights = pow(weights,_BlendExponent);  //进一步控制权重
                return weights/(weights.x+ weights.y+ weights.z);   //使xyz相加=1
            }

            v2f vert (appdata v)
            {
                v2f o;
                o.vertex = UnityObjectToClipPos(v.vertex);
                o.normal = UnityObjectToWorldNormal(v.normal);
                o.worldpos = mul(unity_ObjectToWorld,v.vertex);
                return o;
            }
            fixed4 frag (v2f i) : SV_Target
            {
                //triplanar
                TriUV triuv = GetTriUV(i.worldpos);
                fixed4 colx = tex2D(_SideTex,triuv.xUV * _SideTex_ST.xy + _SideTex_ST.zw);
                fixed4 coly = tex2D(_TopTex,triuv.yUV * _TopTex_ST.xy + _TopTex_ST.zw);
                fixed4 colz = tex2D(_SideTex,triuv.zUV * _SideTex_ST.xy + _SideTex_ST.zw);
                fixed3 weights = GetTriWeights(i.normal);
                fixed4 tricol = colx*weights.x + coly*weights.y +colz*weights.z;
                return tricol;
            }
            ENDCG
        }
    }
}

用顶点位置作为uv坐标

先来映射一个面

fixed4 frag (v2f i) : SV_Target
{
    fixed4 colx = tex2D(_SideTex,i.worldpos.zy);
    fixed4 coly = tex2D(_TopTex,i.worldpos.xz);
    fixed4 colz = tex2D(_SideTex,i.worldpos.xy);
    //return colx;
    //return colx;
    return colx;
}

Image title

可以写成一个函数方便使用

            struct TriUV{
                float2 xUV,yUV,zUV;
            };
            TriUV GetTriUV (float4 worldpos) {
                TriUV triUV;
                triUV.xUV = worldpos.zy;
                triUV.yUV = worldpos.xz;
                triUV.zUV = worldpos.xy;
                return triUV;
            }
            fixed4 frag (v2f i) : SV_Target
            {
            TriUV triuv = GetTriUV(i.worldpos);
                fixed4 colx = tex2D(_SideTex,triuv.xUV);
                fixed4 coly = tex2D(_TopTex,triuv.yUV);
                fixed4 colz = tex2D(_SideTex,triuv.zUV);
            }

合在一起的效果

            fixed4 frag (v2f i) : SV_Target
            {
            TriUV triuv = GetTriUV(i.worldpos);
                fixed4 colx = tex2D(_SideTex,triuv.xUV);
                fixed4 coly = tex2D(_TopTex,triuv.yUV);
                fixed4 colz = tex2D(_SideTex,triuv.zUV);
                return (colx+coly+colz)/3;
            }

Image title

用法线作为权重

            fixed3 GetTriWeights(fixed3 normal){
                fixed3 weights = abs(normal);   //因为normal可能有负数
                return weights/(weights.x+ weights.y+ weights.z);   //使xyz相加=1
            }
            ......
            fixed4 frag (v2f i) : SV_Target
            {
                .....
                fixed3 weights = GetTriWeights(i.normal);
                fixed4 tricol = colx*weights.x + coly*weights.y +colz*weights.z;
                return tricol;
            }

Image title

控制权重

            Properties {
            .....
                _BlendOffset("BlendOffset",Range(0,0.5)) = 0.25
            }
            .....
            fixed _BlendOffset;
           ....
           fixed3 GetTriWeights(fixed3 normal){
                fixed3 weights = abs(normal);   //因为normal可能有负数
                weights = saturate(weights-_BlendOffset);   //控制权重
                return weights/(weights.x+ weights.y+ weights.z);   //使xyz相加=1
            }
            ....
            fixed4 frag (v2f i) : SV_Target
            {
            .....
            fixed3 weights = GetTriWeights(i.normal);
                fixed4 tricol = colx*weights.x + coly*weights.y +colz*weights.z;
                return tricol;
            }

Image title

进一步控制权重

           Properties {
            .....
                _BlendOffset("BlendOffset",Range(0,0.5)) = 0.25
                _BlendExponent ("Blend Exponent", Range(1, 8)) = 2
            }
            .....
           fixed _BlendOffset;
           half _BlendExponent;
           ....
           fixed3 GetTriWeights(fixed3 normal){
                fixed3 weights = abs(normal);   //因为normal可能有负数
                weights = saturate(weights-_BlendOffset);   //控制权重
                weights = pow(weights,_BlendExponent);  //进一步控制权重
                return weights/(weights.x+ weights.y+ weights.z);   //使xyz相加=1
            }
            ....
            fixed4 frag (v2f i) : SV_Target
            {
            .....
            fixed3 weights = GetTriWeights(i.normal);
                fixed4 tricol = colx*weights.x + coly*weights.y +colz*weights.z;
                return tricol;
            }

Image title

接下来我们可以试试映射多张贴图，我们y轴用_TopTex草地贴图，x和z轴用 _MainTex石头贴图。

            Properties {
            .....
                _MainTex ("Texture", 2D) = "white" {}
                _TopTex("",2D) = "white"{}
            }
            ...
            fixed4 frag (v2f i) : SV_Target
            {
                fixed4 colx = tex2D(_MainTex,i.worldpos.zy);
                fixed4 coly = tex2D(_TopTex,i.worldpos.xz);
                fixed4 colz = tex2D(_MainTex,i.worldpos.xy);
             }

Image title

最后我们再实现一下纹理的缩放和位移

float4 _MainTex_ST,_SideTex_ST;
.....
fixed4 frag (v2f i) : SV_Target
{
    fixed4 colx = tex2D(_MainTex,i.worldpos.zy * _MainTex_ST.xy + _MainTex_ST.zw);
    fixed4 coly = tex2D(_TopTex,i.worldpos.xz * _SideTex_ST.xy + _SideTex_ST.zw);
    fixed4 colz = tex2D(_MainTex,i.worldpos.xy * _MainTex_ST.xy + _MainTex_ST.zw);
    ...
}

把缩放设置为5看一下效果

Image title
